VERSION III
| Item | Part nr. (old part nr.) |
Description |
|---|---|---|
| 0 |
55504/03 D1688901015 |
Injector unit 207 Bar opening pressure |
|
55505/03 D1688901016 |
Injector unit 207 Bar opening pressure | |
|
55506/03 D1688901017 |
Injector unit 207 Bar opening pressure | |
|
55507/03 D1688901018 |
Injector unit 207 Bar opening pressure | |
|
55508/03 D1688901019 |
Injector unit 207 Bar opening pressure | |
|
55516/03 D1688901020 |
Injector unit 172 Bar opening pressure | |
| 1 | Cap nut | |
| 2 | Locknut | |
| 3 | Spring nut | |
| 4 | Adjusting screw | |
| 5 | Spring | |
| 6 | Spindle | |
| 7 | Body | |
| 8 |
40003/03 D1688901999 ISO 7440/1 |
Needle valve |
| 9 |
40004/04 D1680103094 |
Orifice plate d. 0,4 mm for 55504/03 |
|
40005/04 D1680103095 |
Orifice plate d. 0,5 mm for 55505/03 | |
|
40006/04 D1680103096 |
Orifice plate d. 0,6 mm for 55505/03 - 55516/03 | |
|
40007/04 D1680103097 |
Orifice plate d. 0,7 mm for 55507/03 | |
|
40008/04 D1680103098 |
Orifice plate d. 0,8 mm for 55508/03 | |
| 10 |
54362/03 D1680320026 |
Spacer |
| 11 | Circlip | |
| 12 | Nut, injector | |
| 13 | Damper | |
| 14 | Bleed screw | |
| 15 | Bleed pipe | |
| 16 | Gasket | |
| 17 | Stud | |
| 18 | 55908/03 | Inlet stud with edge filter |
| 19 | Gasket |
